Alteon OS Command Reference
The Statistics Menu
13743W7774, May 2007
/stats/l2
Layer 2 Statistics
The Layer 2 statistics provided by each menu option are briefly described in Table 5-10, with
pointers to detailed information.
/stats/l2/fdb
FDB Statistics
This menu option enables you to display statistics regarding the use of the forwarding data-
base, including the number of new entries, finds, and unsuccessful searches.
FDB statistics are described in the following table:
[Layer 2 Statistics Menu]
fdb - Show FDB stats
lacp - Show LACP stats
gvrp - GVRP statistics
Table 5-10 Layer 2 Statistics Menu Options (/stats/l2)
Command Syntax and Usage
fdb
Displays FDB statistics. See page 137 for sample output.
lacp <port alias or number>
Displays Link Aggregation Control Protocol (LACP) statistics. See page 138 for sample output.
gvrp
Displays Generic VLAN Registration Protocol (GVRP) statistics. See page 139 for sample output.
FDB statistics:
current: 83 hiwat: 855
Table 5-11 Forwarding Database Statistics (/stats/fdb)
Statistic Description
current Current number of entries in the Forwarding Database.
hiwat Highest number of entries recorded at any given time in the Forwarding
Database.
