Alteon OS Command Reference
136
The Statistics Menu 43W7774, May 2007
/stats/port <port alias or number>/ip
Interface Protocol Statistics
This menu option enables you to display the interface statistics of the selected port.
/stats/port <port alias or number>/link
Link Statistics
This menu enables you to display the link statistics of the selected port.
GEA IP statistics for port INT1:
ipInReceives : 0
ipInHeaderError: 0
ipInDiscards : 0
Table 5-8 Interface Protocol Statistics (/stats/port/ip)
Statistics Description
ipInReceives The total number of input datagrams received from interfaces, including
those received in error.
ipInHeaderErrors The number of input datagrams discarded because the IP address in their
IP header's destination field was not a valid address to be received at this
entity (the switch).
ipInDiscards The number of input IP datagrams for which no problems were encoun-
tered to prevent their continued processing, but which were discarded (for
example, for lack of buffer space). Note that this counter does not include
any datagrams discarded while awaiting re-assembly.
Link statistics for port INT1:
linkStateChange: 1
Table 5-9 Link Statistics (/stats/port/link)
Statistics Description
linkStateChange The total number of link state changes.
