Alteon OS Command Reference
The Statistics Menu
13143W7774, May 2007
/stats/port <port alias or number>/ether
Ethernet Statistics
This menu option enables you to display the ethernet statistics of the selected port
Ethernet statistics for port INT1:
dot3StatsAlignmentErrors: 0
dot3StatsFCSErrors: 0
dot3StatsSingleCollisionFrames: 0
dot3StatsMultipleCollisionFrames: 0
dot3StatsLateCollisions: 0
dot3StatsExcessiveCollisions: 0
dot3StatsInternalMacTransmitErrors: NA
dot3StatsFrameTooLongs: 0
dot3StatsInternalMacReceiveErrors: 0
Table 5-6 Ethernet Statistics for Port (/stats/port/ether)
Statistics Description
dot3StatsAlignment
Errors
A count of frames received on a particular interface that are not an inte-
gral number of octets in length and do not pass the Frame Check
Sequence (FCS) check.
The count represented by an instance of this object is incremented when
the alignmentError status is returned by the MAC service to the
Logical Link Control (LLC) (or other MAC user). Received frames for
which multiple error conditions obtained are, according to the conven-
tions of IEEE 802.3 Layer Management, counted exclusively according
to the error status presented to the LLC.
dot3StatsFCSErrors A count of frames received on a particular interface that are an integral
number of octets in length but do not pass the Frame Check Sequence
(FCS) check.
The count represented by an instance of this object is incremented when
the frameCheckError status is returned by the MAC service to the
LLC (or other MAC user). Received frames for which multiple error con-
ditions obtained are, according to the conventions of IEEE 802.3 Layer
Management, counted exclusively according to the error status presented
to the LLC.
dot3StatsSingle-
CollisionFrames
A count of successfully transmitted frames on a particular interface for
which transmission is inhibited by exactly one collision.
A frame that is counted by an instance of this object is also counted by the
corresponding instance of either the ifOutUcastPkts, ifOutMul-
ticastPkts, or ifOutBroadcastPkts, and is not counted by the
corresponding instance of the dot3StatsMultipleCollision-
Frame object.
