Alteon OS Command Reference
126
The Statistics Menu 43W7774, May 2007
/stats/port <port alias or number>/8021x
802.1x Authenticator Statistics
This menu option enables you to display the 802.1x authenticator statistics of the selected port.
Authenticator Statistics:
eapolFramesRx = 925
eapolFramesTx = 3201
eapolStartFramesRx = 2
eapolLogoffFramesRx = 0
eapolRespIdFramesRx = 463
eapolRespFramesRx = 460
eapolReqIdFramesTx = 1820
eapolReqFramesTx = 1381
invalidEapolFramesRx = 0
eapLengthErrorFramesRx = 0
lastEapolFrameVersion = 1
lastEapolFrameSource = 00:01:02:45:ac:51
Table 5-3 802.1x Authenticator Statistics of a Port (/stats/port/8021x)
Statistics Description
eapolFramesRx Total number of EAPOL frames received
eapolFramesTx Total number of EAPOL frames transmitted
eapolStartFramesRx Total number of EAPOL Start frames received
eapolLogoff-
FramesRx
Total number of EAPOL Logoff frames received
eapolRespId-
FramesRx
Total number of EAPOL Response Identity frames received
eapolRespFramesRx Total number of Response frames received
eapolReqIdFramesTx Total number of Request Identity frames transmitted
eapolReqFramesTx Total number of Request frames transmitted
invalidEapol-
FramesRx
Total number of invalid EAPOL frames received
eapLengthError-
FramesRx
Total number of EAP length error frames received
lastEapolFrameVer-
sion
The protocol version number carried in the most recently received
EAPOL frame.
lastEapolFrame-
Source
The source MAC address carried in the most recently received
EAPOL frame.
