Alteon OS Command Reference
120
The Information Menu 43W7774, May 2007
/info/port
Port Information
NOTE – The sample screens that appear in this document might differ slightly from the screens
displayed by your system. Screen content varies based on the type of BladeCenter unit that you
are using and the firmware versions and options that are installed.
Port information includes:
Port alias
Whether the port uses VLAN tagging or not (y or n)
Port VLAN ID (PVID)
Port name
VLAN membership
Whether the port is configured for Port Fast Fowarding (Fast)
Whether the port is enabled for FDB Learning (Lrn)
Alias Port Tag Fast Lrn PVID NAME VLAN(s)
----- ---- --- ---- --- ---- -------------- ------------------------
INT1 1 y n e 1 INT1 1 10 4095
INT2 2 y n e 1 INT2 1 4095
INT3 3 y n e 1 INT3 1 4095
INT4 4 y n e 1 INT4 1 4095
INT5 5 y n e 1 INT5 1 4095
INT6 6 y n e 1 INT6 1 4095
INT7 7 y n e 1 INT7 1 4095
INT8 8 y n e 1 INT8 1 4095
INT9 9 y n e 1 INT9 1 4095
INT10 10 y n e 1 INT10 1 4095
INT11 11 y n e 1 INT11 1 4095
INT12 12 y n e 1 INT12 1 4095
INT13 13 y n e 1 INT13 1 4095
INT14 14 y n e 1 INT14 1 4095
MGT 15 y n e 4095*MGT 4095
EXT1 17 n n e 1 EXT1 1
EXT2 18 n n e 1 EXT2 1
EXT3 19 y n e 1 EXT3 1 ^10
EXT4 20 y n e 1 EXT4 1 ^30
^ = Dynamic port in this VLAN
* = PVID is tagged.
