Alteon OS Command Reference
110
The Information Menu 43W7774, May 2007
/info/l3/rip
Routing Information Protocol Information
Use this menu to view information about the Routing Information Protocol (RIP)
configuration and statistics.
/info/l3/rip/routes
RIP Routes Information
This table contains all dynamic routes learnt through RIP, including the routes that are under-
going garbage collection with metric = 16. This table does not contain directly connected
routes and locally configured static routes.
/info/l3/rip/dump <interface number>
Show RIP User Configuration
[RIP Information Menu]
routes - Show RIP routes
dump - Show RIP user's configuration
Table 4-31 RIP Information Menu Options (/info/l3/rip)
Command Syntax and Usage
routes
Displays RIP routes. For more information, see page 110.
dump <interface number or zero for all IFs)>
Displays RIP user’s configuration. For more information, see page 110.
>> IP Routing# /info/l3/rip/routes
3.0.0.0/8 via 30.1.1.11 metric 4
4.0.0.0/16 via 30.1.1.11 metric 16
10.0.0.0/8 via 30.1.1.2 metric 3
20.0.0.0/8 via 30.1.1.2 metric 2
RIP USER CONFIGURATION :
RIP on updat 30
RIP Interface 2 : 102.1.1.1, enabled
version 2, listen enabled, supply enabled, default none
poison disabled, trigg enabled, mcast enabled, metric 1
auth none,key none
RIP Interface 3 : 103.1.1.1, enabled
version 2, listen enabled, supply enabled, default none
poison disabled, trigg enabled, mcast enabled, metric 1
