Alteon OS Command Reference
The Information Menu
10743W7774, May 2007
/info/l3/ospf/if
OSPF Interface Information
/info/l3/ospf/dbase
OSPF Database Information
Ip Address 10.10.12.1, Area 0.0.0.1, Admin Status UP
Router ID 10.10.10.1, State DR, Priority 1
Designated Router (ID) 10.10.10.1, Ip Address 10.10.12.1
Backup Designated Router (ID) 10.10.14.1, Ip Address 10.10.12.2
Timer intervals, Hello 10, Dead 40, Wait 1663, Retransmit 5,
Poll interval 0, Transit delay 1
Neighbor count is 1 If Events 4, Authentication type none
[OSPF Database Menu]
advrtr - LS Database info for an Advertising Router
asbrsum - ASBR Summary LS Database info
dbsumm - LS Database summary
ext - External LS Database info
nw - Network LS Database info
nssa - NSSA External LS Database info
rtr - Router LS Database info
self - Self Originated LS Database info
summ - Network-Summary LS Database info
all - All
Table 4-30 OSPF Database Information Menu Options (/info/l3/ospf/dbase)
Command Syntax and Usage
advrtr <router-id (A.B.C.D)>
Takes advertising router as a parameter. Displays all the Link State Advertisements (LSAs) in the
LS database that have the advertising router with the specified router ID, for example: 20.1.1.1.
asbrsum <adv-rtr (A.B.C.D)> | <link_state_id (A.B.C.D> | <self>
Displays ASBR summary LSAs. The usage of this command is as follows:
a) asbrsum adv-rtr 20.1.1.1 displays ASBR summary LSAs having the advertising
router 20.1.1.1.
b) asbrsum link_state_id 10.1.1.1 displays ASBR summary LSAs having the link
state ID 10.1.1.1.
c) asbrsum self displays the self advertised ASBR summary LSAs.
d) asbrsum with no parameters displays all the ASBR summary LSAs.
