Alteon OS Command Reference
The Information Menu
10343W7774, May 2007
/info/l3/bgp/peer
BGP Peer information
Following is an example of the information that /info/l3/bgp/peer provides.
/info/l3/bgp/summary
BGP Summary information
Following is an example of the information that /info/l3/bgp/summary provides.
BGP Peer Information:
3: 2.1.1.1 , version 0, TTL 1
Remote AS: 0, Local AS: 0, Link type: IBGP
Remote router ID: 0.0.0.0, Local router ID: 1.1.201.5
BGP status: idle, Old status: idle
Total received packets: 0, Total sent packets: 0
Received updates: 0, Sent updates: 0
Keepalive: 0, Holdtime: 0, MinAdvTime: 60
LastErrorCode: unknown(0), LastErrorSubcode: unspecified(0)
Established state transitions: 0
4: 2.1.1.4 , version 0, TTL 1
Remote AS: 0, Local AS: 0, Link type: IBGP
Remote router ID: 0.0.0.0, Local router ID: 1.1.201.5
BGP status: idle, Old status: idle
Total received packets: 0, Total sent packets: 0
Received updates: 0, Sent updates: 0
Keepalive: 0, Holdtime: 0, MinAdvTime: 60
LastErrorCode: unknown(0), LastErrorSubcode: unspecified(0)
Established state transitions: 0
BGP Peer Summary Information:
Peer V AS MsgRcvd MsgSent Up/Down State
--------------- - -------- -------- -------- -------- ----------
1: 205.178.23.142 4 142 113 121 00:00:28 established
2: 205.178.15.148 0 148 0 0 never connect
