Alteon OS Command Reference
The Information Menu
10143W7774, May 2007
/info/l3/arp/dump
Show All ARP Entry Information
NOTE – If you have VMA turned on, the referenced port will be the designated port. If you have
VMA turned off, the designated port will be the normal ingress port.
The Flag field is interpreted as follows:
IP address Flags MAC address VLAN Port
--------------- ----- ----------------- ---- ----
47.80.22.1 00:e0:16:7c:28:86 1 INT6
47.80.23.243 P 00:03:42:fa:3b:30 1
47.80.23.245 00:c0:4f:60:3e:c1 1 INT6
190.10.10.1 P 00:03:42:fa:3b:30 10
Table 4-27 ARP Dump Flag Parameters
Flag Description
P Permanent entry created for switch IP interface.
R Indirect route entry.
U Unresolved ARP entry. The MAC address has not been learned.
