Page 448 of 458 Installing a Signaling Server
NN43021-310 Standard 02.02 October 2008
Procedure 81
Logging in to the Signaling Server
Before you begin, make sure the DTE–DTE null modem cable (supplied with
the Signaling Server) runs between the serial port on the back of the Signaling
Server and the maintenance terminal.
1 Make sure the Signaling Server is powered up and connected to the
maintenance terminal. Refer to Signaling Server: Installation and
Commissioning (NN43001-312).
The Signaling Server must boot successfully before the user can log in.
2 Press <CR> to invoke the login prompt.
3 Enter the login credentials by doing one of the following:.
• If the Signaling Server has connected to the Call Server (the startup
messages indicate if the PBX link is up), use the PWD1 login to
access the Signaling Server.
• If the Signaling Server is not connected to the Call Server:
a. Enter the default Signaling Server Command Line Interface
(CLI) login
admin.
b. Enter the Signaling Server Command Line Interface (CLI)
password.
• If this Signaling Server has just been installed and you are
logging in for the first time, enter the default password
cseadmin.
The system immediately prompts you to change the default
password.
• If this is not the first login to the Signaling Server, enter the
appropriate password.
If you have forgotten the password, reset it from the Tools
Menu (see Signaling Server: Installation and
Commissioning (NN43001-312)).
End of Procedure
To log out of the Signaling Server, enter exit at the command line.
