Page 438 of 458 Installing a Signaling Server
NN43021-310 Standard 02.02 October 2008
Depending on whether the Signaling Server is configured as Primary,
Alternate or Stand-alone, the Primary NRS IP address screen (Figure
184), the Alternate NRS IP address screen (Figure 185), or both in
succession (for a Stand-alone Signaling Server) appear.
Figure 184
Primary NRS IP address
Figure 185
Alternate NRS IP address
11 Enter the Primary NRS IP address or the Alternate NRS IP address,
depending on the option entered in step 12 on page 419 or step 13 on
page 420.
•If a was entered in step 13, you can enter the address of the Alternate
NRS if you know it, but it is not required. See Figure 167 on
page 423.
•If b was entered in step 13, enter the address of the Primary NRS.
See Figure 166 on page 423.
•If c was entered in step 13:
— Enter the address of the Primary NRS. See Figure 166.
— Enter the address of the Alternate NRS. See Figure 167.
•If d was entered in step 12:
— Enter the address of the Primary NRS (optional).
CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx)
=====================================================================
Please enter the Primary NRS IP Address:
Primary NRS IP :
CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx)
=====================================================================
Please enter the Alternate NRS IP Address:
Alternate NRS IP :
