Page 434 of 458 Installing a Signaling Server
NN43021-310 Standard 02.02 October 2008
Figure 178
Standalone Signaling Server - NRS
Figure 179
NRS type — co-resident Signaling Server
9 Select the type of NRS to be provided by this Signaling Server. See
Figure 179 for a co-resident Signaling Server. See Figure 178 for a
stand-alone Signaling Server.
• If this Signaling Server is to be the Primary NRS, enter a.
• If this Signaling Server is to be the Alternate NRS, enter b.
• If this Signaling Server is not a stand-alone Signaling Server and is
to be the Fail-safe NRS, enter c.
Refer to IP Peer Networking: Installation and Commissioning
(NN43001-313)
for more information on the NRS.
CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx)
=====================================================================
Please select the Network Routing Service (NRS) configuration for this
Signaling Server.
Please enter:
<CR> -> <a> - H.323 Gatekeeper and SIP Redirect/Proxy Server.
<b> - H.323 Gatekeeper only.
<c> - SIP Redirect/Proxy Server only.
Enter Choice>
CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx)
=====================================================================
Please select the type of Network Routing Service (NRS) for this
Signaling Server.
Please enter:
<CR> -> <a> - Primary.
<b> - Alternate.
<c> - Failsafe.
Enter Choice>
