Installing a Signaling Server Page 431 of 458
Communication Server 1000M and Meridian 1 Large System Installation and Commissioning
4 Enter the location (loop and shelf) of the IPMG board.
Note: If the IPMG has not been configured yet, the loop and shelf
information can be left at the current value. The IPMG board location can
be updated using OAM shell commands after the Signaling Server is
configured.
5 The Leader/Follower configuration screen appears (Figure 175).
Figure 175
Leader/Follower Signaling Server configuration
6 Configure the Signaling Server as a Leader or Follower. If there is already
a Leader Signaling Server in the IP Telephony node, enter b at the prompt
to configure this Signaling Server as Follower. The Follower Signaling
Server configuration screen appears (Figure 176). Go to step 15 on
page 423.
Please select the role of this Signaling Server.
If this Signaling Server will be a Leader then its data networking
and IP Telephony parameters must be entered now. (This will pre-
configure the IP Telephony node files.)
If this Signaling Server will be a Follower then its data networking
and IP Telephony parameters must be configured through Element
Manager later.
Please enter:
<CR> -> <a> - Set this Signaling Server as a Leader.
<b> - Set this Signaling Server as a Follower.
<q> - Quit.
Enter Choice>
=====================================================================
CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx)
Note: This step will over-write all existing configuration parameters
on this Signaling Server.
