Installing a Signaling Server Page 423 of 458
Communication Server 1000M and Meridian 1 Large System Installation and Commissioning
TLAN subnet parameters as required. The Call Server IP address is
automatically set to 0.0.0.0.
Depending on whether the Signaling Server is configured as Primary,
Alternate, or Standalone, either the Primary NRS IP address screen,
the Alternate NRS IP address screen, or both (in succession) appear.
Both screens appear in succession for a Standalone Signaling
Server.
Figure 166
Primary NRS IP address
Figure 167
Alternate NRS IP address
15 Enter the Primary NRS IP address or the Alternate NRS IP address,
depending on the option entered in step 12 on page 419 or step 13 on
page 420.
•If a was entered in step 13, you can enter the address of the Alternate
NRS if you know it, but it is not required. See.
•If b was entered in step 13, enter the address of the Primary NRS..
•If c was entered in step 13:
— Enter the address of the Primary NRS..
— Enter the address of the Alternate NRS.
•If d was entered in step 12:
CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx)
=====================================================================
Please enter the Primary NRS IP Address:
Primary NRS IP :
CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx)
=====================================================================
Please enter the Alternate NRS IP Address:
Alternate NRS IP :
