Installing a Signaling Server Page 421 of 458
Communication Server 1000M and Meridian 1 Large System Installation and Commissioning
Depending on whether the Signaling Server is configured as Leader or
Standalone, either the Leader Signaling Server configuration screen
(Figure 164) or the Standalone Signaling Server configuration screen
(Figure 165) appears.
Figure 164
Leader Signaling Server configuration
CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx)
=====================================================================
Please enter the data networking and IP Telephony parameters for
this Leader Signaling Server.
Node ID : 276
Hostname : SS_Node276_Ldr
ELAN IP : 192.168.10.20
ELAN subnet mask: 255.255.255.0
ELAN gateway IP : 192.168.10.1
TLAN IP : 192.168.20.20
TLAN subnet mask: 255.255.255.0
TLAN gateway IP : 192.168.20.1
Node IP : 192.168.10.20
Call Server IP : 192.168.10.10
