Page 406 of 458 Installing a Signaling Server
NN43021-310 Standard 02.02 October 2008
The system verifies the file systems.
• If the hard drive of the Signaling Server is not partitioned, the file
systems verification process fails. Upon failure, the menu in
Figure 145 appears.
Figure 145
File systems verification failure
a. Enter a to partition and initialize the hard disk, and to reboot the
Signaling Server.
The system displays the messages:
Partitioning hard disk ...
Hard disk partitioning succeeded.
Creating filesystems ...
Filesystems creation succeeded.
Rebooting system ...
b. The Install Tool banner screen (Figure 144 on page 405)
reappears. Go back to beginning of Step 2.. If the hard drive of
the Signaling Server is partitioned, the following system
messages appear.
Filesystems verification succeeded.
c. Confirm or enter the date and time (Figure 146 on page 407).
CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx)
=====================================================================
The filesystems verification failed! (This is normal for a new
system.)
The hard disk must be (re)partitioned and (re)initialized. This will
erase all data on the hard disk. The system will then reboot and
the Install Tool will restart.
Please enter:
<CR> -> <a> - Partition and initialize the hard disk, then reboot.
Enter Choice> a
