Installing a Signaling Server Page 401 of 458
Communication Server 1000M and Meridian 1 Large System Installation and Commissioning
Installing the Signaling Server software
Introduction
This section provides installation procedures for CS 1000 Release 5.5
Signaling Server software on an IBM X306m or HP DL320-G4 Signaling
Server.
Before you begin
Before installing the software, you must do the following:
• Connect and power up the Signaling Server. See “Connections” on
page 391.
• For CP PM Signaling Servers, ensure that Switch S5 is set to position 2
(to support the internal hard disk drive)
• For IBM X306m and HP DL320-G4 Signaling Servers, you must obtain
the CS 1000 Release 5.5 Signaling Server Software Install CD.
IMPORTANT!
The Signaling Server is out-of-service during software upgrade.
IMPORTANT!
CP PM, IBM X306m and HP DL320-G4 Signaling Servers do not
support any Signaling Server software prior to CS 1000 Release 5.5.
IMPORTANT!
CS 1000 Release 5.5 Signaling Server software does not need to be
installed on the CP PM Signaling Server. It is delivered with the
Signaling Server software, operating system, applications and web files
pre-loaded onto the hard drive. Only basic system configuration
parameters need to be entered on the first boot of the CP PM Signaling
Server.
