Page 388 of 458 Installing a Signaling Server
NN43021-310 Standard 02.02 October 2008
Table 64
Readiness checklist (Part 1 of 2)
Have you:
Read all safety instructions in Communication Server 1000E: Installation and
Commissioning (NN43041-310) or Communication Server 1000M and Meridian 1 Large
System Installation and Configuration (NN43021-310), as appropriate for your CS 1000
system?
Received all equipment and peripherals?
For a Nortel ISP1100 (NTDU27AA), IBM X306m (NTDU99AAE5), and HP DL320-G4
(NTDU97AA) Signaling Servers:
• installation accessories for rack-mounting the server
•AC-power cord
• a DTE-DTE null modem cable (supplied)
For a CS 1000E Nortel CP PM Signaling Server (NTDW61BAE5):
• NTDW6102E5 - CP PM Signaling Server Hard Drive kit
• N0118766 - CP PM Signaling Server Hard Drive Installation instructions
• NTAK19ECE6 - CP PM Signaling Server 2 port SDI Cable assembly kit
• NTDU0606E6 - CP PM Signaling Server 25cm RJ45 Ethernet Cable kit
• a DTE-DTE null modem cable (supplied)
• for a CS 1000M Nortel CP PM Signaling Server (NTDW66AAE5 model)
• NTDW6102E5 - CP PM Signaling Server Hard Drive kit
• N0118766 - CP PM Signaling Server Hard Drive Installation instructions
• NTAK19ECE6 - CP PM Signaling Server 2 port SDI Cable assembly kit
• NTDW69AAE5 - CP PM Signaling Server Large System Cabling kit
• N0106745 - CP PM Signaling Large System Cabling
• a DTE-DTE null modem cable (supplied)
Note: Save the packaging container and packing materials in case you must ship the
product.
