Page 342 of 458 Performing acceptance tests
NN43021-310 Standard 02.02 October 2008
On the LCD displays on the Cards:
• Following the “Selftest Complete” message, watch the LCD for the
message “IOP in Slot 17.”
• Watch the LCD for the message “Loading Disk OS.”
• When the sysload is complete, the system terminal displays DONE
and the system automatically invokes the initialization program.
The following functions occur when the initialization is complete:
• The column LED should go out.
• The major alarm indication should disappear from all attendant
consoles.
• The system automatically runs the programs in the midnight routine.
2 Press the return key on the system terminal to monitor the progress of the
midnight routines until the OVL111 BKGD response is received.
End of Procedure
Testing the system terminal and system monitor
Use Procedure 62 to test the system terminals connected to the Large System.
Procedure 62
Testing system terminal and system monitor
1 Log into the system:
LOGI (password)
2 Enter the program and check the status of the system monitor:
LD 37
STAT XSM
3 Test the terminal:
TTY x “x” is the device number assigned to the system terminal
The system terminal should display
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
