Powering up the system and initial loading Page 319 of 458
Communication Server 1000M and Meridian 1 Large System Installation and Commissioning
7 Select the keycode to be used on the system.The system validates the
selected keycode and displays the software release and machine type
authorized.
Note: The software release displayed depends on the keycode file
content. The machine type displayed can be one of the following,
according to the keycode content:
• 3521 (CP PIV processor on CS 1000M SG) for Meridian 1 Option
61C CP PIV
• 3621 (CP PIV processor on CS 1000M MG) for CS 1000E and
Meridian 1 Option 81C CP PIV systems
8 The system requests keycode validation.
Validating keycode ...
Copying "/cf2/keycode/KCport60430m.kcd" to "/u/
keycode" -
Copy OK: 1114 bytes copied
The provided keycode authorizes the install of
xxxx software (all subissues) for machine type
xxxx (CPP4 processor on xxxx).
Communication Server 1000 Software/Database/
BOOTROM RMD Install Tool
================================================
Please confirm that this keycode matches the
System S/W on the RMD.
Please enter:
<CR> -> <y> - Yes, the keycode matches.
Go on to Install Menu.
<n> - No, the keycode does not match.
Try another keycode.
Enter choice>
