Page 318 of 458 Powering up the system and initial loading
NN43021-310 Standard 02.02 October 2008
At this point, either replace the RMD or quit the installation. If you select
option “<q> - Quit.”, the system requires confirmation.
If “y” (quit) is selected, the system prints “INST0127 Keycode file is
corrupted. Check Keycode file.” and returns to the installation main menu.
After accessing the RMD containing the valid keycode(s), press <CR>.
The system displays the keycode file(s) available as in the following
example:
Note: A maximum of 20 keycode files can be stored under the “keycode”
directory on the RMD. The keycode files must have the same extension
“.kcd”.
Communication Server 1000 Software/Database/
BOOTROM RMD Install Tool
================================================
====================
You selected to quit. Please confirm.
Please enter:
<CR> -> <y> - Yes, quit.
<n> - No, DON’T quit.
Enter choice>
The following keycode files are available on the
removable media:
Name Size Date Time
-------------------- ------- -----
<CR> -> <1> -keycode.kcd 1114 Jan-17-2005 15:31
<2> - KCport60430m.kcd 1114 Feb-24-2005 13:43
<q> - Quit
Enter choice> 2
