Powering up the system and initial loading Page 317 of 458
Communication Server 1000M and Meridian 1 Large System Installation and Commissioning
6 The system then enters the Main Menu for keycode authorization.
The system searches for available keycode files in the “keycode” directory
on the RMD. If no keycode file is found, the system displays the following
menu:
M A I N M E N U
The Software Installation Tool will install or
upgrade Communication Server 1000 Software,
Database and the CP-BOOTROM. You will be prompted
throughout the installation and given the
opportunity to quit at any time.
Please enter:
<CR> -> <u> - To Install menu
<t> - To Tools menu.
<q> - Quit.
Enter Choice> <u>
Communication Server 1000 Software/Database/
BOOTROM RMD Install Tool
================================================
====================
No keycode files are available on the removable
media.
Please replace the RMD containing the keycode
file(s).
Please enter:
<CR> -> <a> - RMD is now in the drive.
<q> - Quit.
Enter choice>
