Page 272 of 458 Cabling lines and trunks
NN43021-310 Standard 02.02 October 2008
Table 38
NT8D37 IPE Module: NT8D15 E&M Trunk Card 2-wire paging mode
pair-terminations
Pair Pin numbers Pair color Unit
0T/0R
A/PG
26/1
29/4
W-BL/BL-W
W-BR/BR-W
0
1T/1R
A/PG
30/5
33/8
W-S/S-W
R-G/G-R
1
2T/2R
A/PG
34/9
37/12
R-BR/BR-R
BK-O/O-BK
2
3T/3R
A/PG
38/13
41/16
BK-G/G-BK
Y- B L / B L - Y
3
Note: Each of the following I/O panel connectors is cabled as shown
above: connectors A, B, C, D, E, F, G, H, K, L, M, N, R, S, T, and U. These
connectors are associated with backplane slots 0 through 15, sequentially.
Table 39
NT8D37 IPE Module: NT8D15 E&M Trunk Card 2-wire type 1 mode
pair-terminations (Part 1 of 2)
Pair Pin numbers Pair color Unit
0T/0R
E/M
26/1
28/3
W-BL/BL-W
W-G/G-W
0
1T/1R
E/M
30/5
32/7
W-S/S-W
R-O/O-R
1
2T/2R
E/M
34/9
36/11
R-BR/BR-R
BK-BL/BL-BK
2
