Page 270 of 458 Cabling lines and trunks
NN43021-310 Standard 02.02 October 2008
14T/14R 39/14 BK-BR/BK-BR 13
15T/15R 40/15 BK-S/S-BK 14
16T/16R 41/16 Y-BL/BL-Y 15
17T/17R 42/17 Y-O/O-Y 16
18T/18R 43/18 Y-G/G-Y 17
19T/19R 44/19 Y-BR/BR-Y 18
20T/20R 45/20 Y-S/S-Y 19
21T/21R 46/21 V-BL/BL-V 20
22T/22R 47/22 V-O/V-O 21
23T/23R 48/23 V-G/G-V 22
24T/24R 49/24 V-BR/BR-V 23
25T/25R 50/25 V-S/S-V Spare
Note: Each of the following I/O panel connectors is cabled as shown
above: connectors A, B, C, D, E, F, G, H, K, L, M, N, R, S, T, and U. These
connectors are associated with backplane slots 0 through 15, sequentially.
Table 36
NT8D37 IPE Module: line card pair-terminations (Part 2 of 2)
Pair Pin numbers Pair color
Unit
24/card
