Page 254 of 458 Cabling network modules and loops
NN43021-310 Standard 02.02 October 2008
5 Install the remaining cables according to the assignments in Table 32 on
page 250.
End of Procedure
Cabling a Superloop Network Card – single column
If the system is configured in multiple columns, see “Basic cabling for
multiple-row network connections” on page 258.
Procedure 43
Basic cabling for single-row network connections
1 Refer to the work order and the cabling layout shipped with the system to
determine:
• each loop number assigned
• the module and slot assignments for the NT8D04 Superloop Network
Card associated with each loop
• the location of NT8D37 IPE Modules that contain NT8D01 Controller
Cards associated with each loop
2 Set the Enb/Dis switch on each superloop network card to Dis.
CAUTION
System Failure
Due to the possibility of EMI/RFI noise, do not route
cables from front to rear next to the power supply
unit.
