Cabling network modules and loops Page 251 of 458
Communication Server 1000M and Meridian 1 Large System Installation and Commissioning
cCNI to 3PE Fanout panel cable connections
The cCNI slot and port connections are labeled on the Fanout panel (see
Figure 108). Each 3PE card is connected with two cables: one to J3 and one
to J4. Table 32 on page 250 specifies the Network group that connects to each
slot.
Figure 108
Fanout panel (Core/Net module)
j3 slot 9 port 0 j4 slot 9 port 0
Group 0
Group 1Group 2
Group 3Group 4Group 5
Group 6
Group 7
j3
slot 9
port 1
j4
slot 9
port 1
j3
slot 10
port 0
j4
slot 10
port 0
j3
slot 10
port 1
j4
slot 10
port 1
j3
slot 11
port 0
j4
slot 11
port 0
j3
slot 11
port 1
j4
slot 11
port 1
j3
slot 12
port 0
j4
slot 12
port 0
j3
slot 12
port 1
j4
slot 12
port 1
