Page 238 of 458 Cabling Common Equipment in a Multi Group system
NN43021-310 Standard 02.02 October 2008
a. At Clock 0: Connect the “J1 Clock” end of a Clock to FIJI cable
(NTRC46Ax) to the J1 end of the Clock to Clock cable.
b. At Clock 1: Connect the “J1 Clock“ end of a second Clock to FIJI
cable (NTRC46Ax) to the J2 end of the Clock to Clock cable.
3 Connect the Clock 0 to FIJI cable:
a. Connect P1 of the NTRC46 cable from Clock 0 to J4 of the FIJI card
in Group 0, Shelf 0.
b. Connect P2 of the NTRC46 cable from Clock 0 to J4 of the FIJI card
in Group 0, Shelf 1.
4 Connect a Clock 1 to FIJI cable:
a. Connect P1 of the NTRC46 cable from Clock 1 to J3 of the FIJI card
in Group 0, Shelf 0.
b. Connect P2 of the NTRC46 cable from Clock 1 to J3 of the FIJI card
in Group 0, Shelf 1.
End of Procedure
