Cabling Common Equipment in a Multi Group system Page 227 of 458
Communication Server 1000M and Meridian 1 Large System Installation and Commissioning
Required cables
Table 31 on page 227 outlines the required cables. Cable lengths will vary
depending on system configuration.
Table 31
Required cables
Cable type Quantity Order Code Description
Fiber Ring cable 1 per FIJI card NTRC48AB 1.8 m (6 ft) fiber optic cable
NTRC48BB 3 m (10 ft) fiber optic cable
NTRC48CB 3.6 m (12 ft) fiber optic cable
NTRC48DA 4.25 m (14 ft) fiber optic cable
NTRC48EA 5.8 m (19 ft) fiber optic cable
NTRC48FA 7.9 m (26 ft) fiber optic cable
Clock to FIJI 2 per system NTRC46AB 1.2 m to 4.1 m (4 ft to 13.5 ft)*
NTRC46BB 1.65 m to 2.4 m (5.5 ft. to 8 ft)*
NTRC46CB 6.7 m (22 ft)*
Clock to Clock 1 per system NTRC49AA 1.8 m (6 ft)
NTRC49BA 6 m (20 ft)
FIJI to FIJI Sync 1 per network group NTRC47AA 1.5 m (5 ft)
* Indicates the lengths of the two “Y” terminations.
