Page 210 of 458 Cabling Common Equipment in a Multi Group system
NN43021-310 Standard 02.02 October 2008
Reviewing Core/Net module placement
Core/Net modules are installed side-by-side on top of separate pedestals, for
power and cooling redundancy. Core/Net 1 is always on the left. Core/Net 0
is always on the right (see Figure 87 on page 211).
Reviewing required Core cards
All Core cards are installed in the factory. See Table 26 on page 210 for the
Core card requirements for each Core/Net module. Refer to “System
equipment – UEMs” on page 38 for module and card descriptions.
Table 26
Required Core cards (minimum per Core/Net module)
Order Code Description
Number required per
Core/Net module
Backplane
side
NT4N65 cCNI: cPCI Core Network Interface
Card
1 to 4
1
front
NT4N48 System Utility Card 1 front
NT4N39AA CP PIV Call Processor Card
(512 MB memory)
1 front
N0026096 MMDU blank faceplate 1 front
Note 1: Each cCNI card supports two Network groups. The number of cCNI cards in each
system depends on the number of Network groups installed in the system. See the System
Layout plan to determine the number and placement of cCNI cards.
