Page 200 of 458 Cabling Common Equipment in a Single Group system
NN43021-310 Standard 02.02 October 2008
Procedure 26
Connecting the 3PE faceplates in the Core/Net modules
1 Connect a NT8D80 cable from the J4 port in the Core/Net 0 3PE card to
J4 port in the Core/Net 1 3PE card.
2 Connect a second NT8D80 cable from the J3 port in Core/Net 0 to the J3
port in Core/Net 1.
Note: The 3PE cards are located in Core/Net slot 11.
End of Procedure
Inspecting CNI to 3PE factory installed cables
New NT4N29AA cables must be installed for existing Network Group 0. If
the system has XSDI cards, reinstall the cards and attach the cables.
Procedure 27
Inspecting NT4N29AA factory installed cables
1 If Network Group 0 will be in the Core/Net, the factory configuration of the
new Core/Net modules is correct. Continue on to “Connecting the Core/
Net backplanes” on page 202.
2 If Network Group 0 will not be in the Core/Net module, reconfigure the
processor module.
Note: Reconfiguration of the processor module is required to allow for
concurrent or future use of the Network portion of the Core/Net for a
higher Network group. The NT4N40 shelf (card cage) is factory installed
with NT4N29 cables and is configured as Group 0.
