Page 156 of 458 Configuring the system monitor
NN43021-310 Standard 02.02 October 2008
Table 11
SW2 on slaves—total unit number for the slaves (Part 1 of 2)
Slave unit
address
Switch position
Slave unit
address
Switch position
3 4 5 6 7 8 3 4 5 6 7 8
** 32 off on on on on on
1 on on on on on off 33 off on on on on off
2 on on on on off on 34 off on on on off on
3 on on on on off off 35 off on on on off off
4 on on on off on on 36 off on on off on on
5 on on on off on off 37 off on on off on off
6 on on on off off on 38 off on on off off on
7 on on on off off off 39 off on on off off off
8 on on off on on on 40 off on off on on on
9 on on off on on off 41 off on off on on off
10 on on off on off on 42 off on off on off on
11 on on off on off off 43 off on off on off off
12 on on off off on on 44 off on off off on on
13 on on off off on off 45 off on off off on off
14 on on off off off on 46 off on off off off on
15 on on off off off off 47 off on off off off off
16 on off on on on on 48 off off on on on on
17 on off on on on off 49 off off on on on off
18 on off on on off on 50 off off on on off on
19 on off on on off off 51 off off on on off off
20 on off on off on on 52 off off on off on on
21 on off on off on off 53 off off on off on off
22 on off on off off on 54 off off on off off on
23 on off on off off off 55 off off on off off off
24 on off off on on on 56 off off off on on on
25 on off off on on off 57 off off off on on off
26 on off off on off on 58 off off off on off on
27 on off off on off off 59 off off off on off off
28 on off off off on on 60 off off off off on on
29 on off off off on off 61 off off off off on off
30 on off off off off on 62 off off off off off on
