Page 154 of 458 Configuring the system monitor
NN43021-310 Standard 02.02 October 2008
with CPU 1 as slave unit 1. Number the slaves sequentially wherever
possible.
Table 8
Switch settings for master in multiple-column system
Switch 123 4 5678
SW1 off off * on** off off off off
SW2 on off To configure positions 3–8, see Table 10
SW3 on on on on
* Set to on for a DC-powered system; set to off for an AC-powered system.
** Set to off if the system is not equipped with a PFTU.
Table 9
Switch settings for slaves in multiple-column system
Switch 12345678
SW1 off off * ** off off off off
SW2 off off To configure positions 3–8, see Table 11 on
page 156
SW3 off off off off
* Set to on for a DC-powered system; set to off for an AC-powered system.
** Set to on to enable PFTU (if equipped) during over-temperature
condition.
Set to off to disable PFTU during over-temperature condition.
Table 10
SW2 on master—total number of slaves in the system (Part 1 of 2)
How many
slave units
Switch position
How many
slave units
Switch position
3 4 5 6 7 8 3 4 5 6 7 8
0 on on on on on on 32 off on on on on on
1 on on on on on off 33 off on on on on off
2 on on on on off on 34 off on on on off on
3 on on on on off off 35 off on on on off off
