62 Technical specifications
The following table lists the DC output power specifications.
Parameter
Specifications
Output power (maximum) 1462 W (1372 W + 90 W fans)
Modules 3.3 V @ 150 A
12 V @ 72 A
Fans 12 VDC @ 7.5 A/ 24 A peak
Mean time before failure (MTBF) 108 803 hr
(Bellcore TR–332 standard)
Ethernet Routing Switch 8005DI DC power supply specifications
This section provides power ratings for the 8005DI DC power supply.
The following table lists the DC input power specifications.
Parameter
Specifications
Input voltage –40Vdc/–75Vdc
Input current 48.75A /32.5A
Input VA (maximum) 1.95 kVA
Input power consumption 1950 W
Heat dissipation (thermal/output) 1666 Btu/hr
The following table lists the DC output power specifications.
Parameter
Specifications
Output power (maximum) 1462 W continuous, 1660 W peak with forced
air cooling
Modules 3.3 V @ 150 A
12 V @ 72 A
Fans 12 VDC @ 7.5 A/ 24 A peak
Mean time before failure (MTBF) 108 803 hr
(Bellcore TR–332 standard)
