Ethernet Routing Switch Installation Guide

Ethernet Routing Switch 8301 AC power supply specifications 59
Table 10
Ethernet Routing Switch 8306 international regulatory requirements (cont’d.)
International regulatory requirements
Europe: EN 55022-1998 Class A; EN 61000-3-2/A14,
EN 61000-3-3 (CE Marking)
Australia/New
Zealand:
AS/NZS 3548:1995, Class A
Japan: VCCI-V3/97.04, Class A
Taiwan: CNS 13438, Class A
Electromagnetic immunity regulatory requirements:
Global basis for
certification:
CISPR 24:1997
Europe: EN 55024:1998
Safety regulatory requirements:
Global basis for
certification:
IEC 60950 current edition with all CB member
deviations
U.S.: UL60950
Canada: CSA 22.2 No. 60950
Europe: EN60950 (CE Marking)
Australia/New
Zealand:
AS/NZS 3260
Mexico: NOM-019-SCFI-1998
Ethernet Routing Switch 8301 AC power supply specifications
The following table lists the power specifications for the 8301 AC power
supply.
Table 11
Ethernet Routing Switch 8301 AC power specifications
AC Input Power Ratings
Input voltage range (nominal): 100-120 VAC 200-240 VAC
Input current (nominal): 16 amperes (A) 12 A
Frequency range (nominal): 50-60 Hertz (Hz) 50-60 Hz
Input VA 1600 volt-amperes VA 2234 VA
Input power consumption: 1584 watts (W) 2212 W
Heat dissipation
(thermal/output):
1515 British Thermal
Units (BTU)/hour (hr)
1508 BTU/hr
Hold-up time: 20 milliseconds (ms)
20 ms
