Ethernet Routing Switch Installation Guide

58 Technical specifications
Table 8
Ethernet Routing Switch 8306 physical specifications (cont’d.)
Physical specifications
Weight (fully loaded): 140 lb (63 kg)
Cooling system:
Fan tray: 1 per chassis
Fans: 6 per fan tray
Thermal sensors: 1 per fan tray
Environmental specifications
The following table lists the environmental specifications of the Ethernet
Routing Switch 8306 chassis.
Table 9
Ethernet Routing Switch 8306 environmental specifications
Environmental specifications
Operating temperature:
0
Cto40
C (32 F to 104
F)
Storage temperature:
–25
Cto70
C (–13 F to 158 F)
Operating humidity: 85% maximum relative humidity, noncondensing
Storage humidity: 95% maximum relative humidity, noncondensing
Operating altitude: 3048 m (10,000 ft) maximum
Storage altitude: 3048 m (10,000 ft) maximum
Free fall/drop: ISO 4180-s, NSTA 1A
Vibration: IEC 68-2-6/34
Shock/bump: IEC 68-2-27-29
International regulatory requirements
The following table lists the international regulatory requirements of the
Ethernet Routing Switch 8306 chassis.
Table 10
Ethernet Routing Switch 8306 international regulatory requirements
International regulatory requirements
Electromagnetic emissions regulatory requirements:
Global basis for
certification:
CISPR 22-1997 Class A
U.S.: FCC CFR47 Part 15, Subpart B, Class A
Canada: ICES-003, Issue-2, Class A
