56 Technical specifications
Table 5
Ethernet Routing Switch 8310 chassis physical specifications (cont’d.)
Physical specifications
Depth: 19.9 in. (50.5 cm)
Weight (empty): 85 pounds (lb) (39 kilograms [kg])
Weight (fully loaded): 225 lb (102 kg)
Cooling system:
Fan trays: 2 per chassis
Fans: 8 per fan tray
Thermal sensors: 1 per fan tray
Environmental specifications
The following table lists the environmental specifications of the Ethernet
Routing Switch 8310 chassis.
Table 6
Ethernet Routing Switch 8310 chassis environmental specifications
Environmental specifications
Operating temperature:
0 degrees Celcius(
C) to 40
C (32 degrees
Fahrenheit [
F] to 104 F)
Storage temperature:
–25
Cto70
C (–13 F to 158 F)
Operating humidity: 85% maximum relative humidity, noncondensing
Storage humidity: 95% maximum relative humidity, noncondensing
Operating altitude: 3 048 meters (m) (10 000feet [ft]) maximum
Storage altitude: 3 048 m (10 000 ft) maximum
Free fall/drop: ISO 4180-s, NSTA 1A
Vibration: IEC 68-2-6/34
Shock/bump: IEC 68-2-27-29
International regulatory requirements
The following table lists the international regulatory requirements of the
Ethernet Routing Switch 8310 chassis.
Table 7
Ethernet Routing Switch 8310 international regulatory requirements
International regulatory requirements
Electromagnetic emissions
regulatory requirements:
Global basis for certification: CISPR 22-1997 Class A
