52 Part Numbers
Table 4
Ethernet Routing Switch 8300 hardware part numbers (cont’d.)
Part number Item Additional details
DS1404099-E5 Ethernet Routing Switch
8394SF CPU/Switch Fabric
module with 2 - 10 Gigabit
Ethernet XFP slots
Includes PCMCIA flash
memory card.
One switch fabric module is
required for each Ethernet
Routing Switch 8300 chassis.
DS1404077-E5 Ethernet Routing Switch
8348TX module. 48 port
autosensing 10BASET/
100BASE-TX Ethernet
interface module
DS1404078
Ethernet Routing Switch
8348TX-PWR module, 48
10BASE-T/100BASE-TX ports
Ethernet interface module
DS1404079-E5
Ethernet Routing Switch
8324GTX module, 24 port
autonegotiating (10BASE-T,
100BASE-TX, or 1000BASE-T)
Ethernet interface module
DS1404098-E5 Ethernet Routing Switch
8324FX. 24 Port 100Base-FX
Ethernet interface module
DS1404093-E5 Ethernet Routing Switch
8348GTX module. 48
port Autosensing 10Base-
T/100Base-TX/1000Base-T
Ethernet interface module
DS1404094-E5
Ethernet Routing Switch
8348GTX-PWR module, 48
port Autonegotiating 10BASE-T
/100BASE-TX / 1000BASE-T,
Ethernet interface module
DS1404095-E5 Ethernet Routing Switch
8348GB module. 48 port SFP
interface module
DS1404100-E6
Ethernet Routing Switch
8308XL module 8 port 10
GBase XFP Ethernet interface
module
The 10GBASE-R ports on this
module are LAN-capable and
operate in full-duplex mode.
Nortel Ethernet Routing Switch 8300
Installation — Chassis
NN46200-309 01.01 Standard
16 June 2008
Copyright © 2008 Nortel Networks
.
