Part Numbers
This chapter provides a list of Nortel Ethernet Routing Switch 8300
hardware and part numbers.
The following table lists Ethernet Routing Switch 8300 hardware and part
numbers.
Table 4
Ethernet Routing Switch 8300 hardware part numbers
Part number Item Additional details
DS1402007-E5 8310 10 slot Power over
Ethernet (PoE) chassis
Includes chassis, dual
backplane, two fan trays,
RS232 cable the for the
management console, rack
mount kit, and cable guide kit.
Requires at least one 83XX
power supply, and up to three
power supplies are supported.
DS1402008-E5 8306 6 slot PoE chassis Includes chassis, dual
backplane, two fan trays,
RS232 cable the for the
management console, rack
mount kit, and cable guide kit.
Requires at least one 83XX
power supply, and up to three
power supplies are supported.
DS1404076-E5 Ethernet Routing Switch
8393SF CPU/Switch Fabric
module with 8 Gigabit Ethernet
SFP slots
Includes Personal Computer
Memory Card International
Association (PCMCIA) flash
memory card.
One switch fabric module is
required for each Ethernet
Routing Switch 8300 chassis.
Nortel Ethernet Routing Switch 8300
Installation — Chassis
NN46200-309 01.01 Standard
16 June 2008
