Ethernet Routing Switch 8310 and 8306
chassis installation
This section describes how to install the Ethernet Routing Switch 8310
and 8306 chassis.
CAUTION
ESD
To prevent damage from electrostatic discharge, always wear
an antistatic wrist strap connected to an electrostatic discharge
(ESD) jack when performing maintenance on this product.
Ensure that the wrist strap makes contact with your skin.
Prerequisites
•
Inspect all items for shipping damage. If you detect damage, do not
install the chassis. Call the Nortel Technical Solutions Center in your
area.
• Verify that the items in the shipping container match those on the
shipment packing list. Use Table 3 "Chassis shipping accessories:
Ethernet Routing Switch 8310 and 8306 chassis" (page 29) as a
checklist when verifying the contents of the shipping container.
• Verify that you have supplied all the other required hardware.
• Ensure that your installation site meets the physical, electrical, and
environmental requirements described in “Site requirements” (page
27).
Chassis installation procedures
This task flow shows you the sequence of procedures you perform to
install the chassis. To link to a procedure, click the procedure title in
“Navigation” (page 34).
