Nortel Ethernet Routing Switch 8300 Installation — Chassis Release: 4.1 Document Revision: 01.01 www.nortel.com NN46200-309 .
Nortel Ethernet Routing Switch 8300 Release: 4.1 Publication: NN46200-309 Document status: Standard Document release date: 16 June 2008 Copyright © 2008 Nortel Networks All Rights Reserved. Printed in Canada and the United States of America LEGAL NOTICE While the information in this document is believed to be accurate and reliable, except as otherwise expressly agreed to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF ANY KIND, EITHER EXPRESS OR IMPLIED.
. Contents Regulatory Information and Safety Precautions 5 EN 55 022 Statements 6 EN 300386 Statement 6 European Union and European Free Trade Association (EFTA) Notice 7 Denan Statement (Japan/Nippon only) 10 Safety Messages 10 Notices 11 Software license 15 New in this release 19 Features 19 8005DC power supply 19 Dual input DC-DC switching power supply Other changes 19 Document changes 19 19 Introduction Navigation 21 21 Chassis installation fundamentals 23 Ethernet Routing Switch 8310
Mounting the Ethernet Routing Switch 8310 and 8306 chassis in an equipment rack 36 Procedure job aid: Maximum number of chassis installed in 7-foot rack 40 Installing the cable guides 40 Switch operations 43 Powering on DC power supplies 43 Powering on AC power supplies 44 Resetting the switch 45 Installing removable flash memory cards 46 Removing removable flash memory cards 47 Protecting memory card files 48 Part Numbers 51 Technical specifications 55 Ethernet Routing Switch 8310 chassis specifi
. Regulatory Information and Safety Precautions Read the information in this section to learn about regulatory conformities and compliances.
Regulatory Information and Safety Precautions ICES Statement (Canada only) Canadian Department of Communications Radio Interference Regulations This digital apparatus (8300 Series chassis and installed components) does not exceed the Class A limits for radio-noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.
MIC notice for 8310, and 8306 chassis (Republic of Korea only) European Union and European Free Trade Association (EFTA) Notice All products labeled with the CE marking comply with R&TTE Directive (1999/5/EEC) which includes the Electromagnetic Compliance (EMC) Directive (2004/108/EC) and the Low Voltage Directive (2006/95/EC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Norms (ENs).
Regulatory Information and Safety Precautions National Safety Statements of Compliance CE Marking Statement (Europe only) EN 60 950 Statement This is to certify that the Nortel 8300 Series chassis and components installed within the chassis are in compliance with the requirements of EN 60 950 in accordance with the Low Voltage Directive. Additional national differences for all European Union countries have been evaluated for compliance.
Información NOM (unicamente para México) Fax: 52 5 480 2199 Input: (8306 and 8310 Chassis only) 8301AC: 100 to 240 VAC 16A 47 to 60 Hz per power supply 8301AC: 200 to 240 VAC 12 A 47 to 60 Hz per power supply single supply, single supply + one redundant supply, two supplies, or two supplies + one redundant supply configurations 8302AC: 100 to 240 VAC 12A 47 to 60 Hz per power supply 8302AC: 200 to 240 VAC 10A 47 to 60 Hz per power supply single supply, single supply + one redundant supply, two supplies,
Regulatory Information and Safety Precautions Fax: 52 5 480 2199 Embarcar a: (8306 and 8310 Chassis) 8301AC:100 to 240 VAC 16A 47 to 60 Hz por fuente de poder 8301AC: 200 to 240 VAC 12 A 47 to 60 Hz por fuente de poder una fuente, una fuente + configuraciones de una fuente redundante, dos fuentes o dos + configuraciones de una fuente redundante 8302AC:100 to 240 VAC 12A 47 to 60 Hz por fuente de poder 8302AC: 200 to 240 VAC 10 A 47 to 60 Hz por fuente de poder una fuente, una fuente + configuraciones
Safety Messages 11 Notices Notice paragraphs alert you about issues that require your attention. The following sections describe the types of notices. For a list of safety messages used in this guide and their translations, see "Translations of safety messages". Attention Notice ATTENTION An attention notice provides important information regarding the installation and operation of Nortel products.
Regulatory Information and Safety Precautions Caution Notice CAUTION Caution notices provide information about how to avoid possible service disruption or damage to Nortel products. CAUTION ATTENTION La mention Attention fournit des informations sur les moyens de prévenir une perturbation possible du service et d’éviter d’endommager les produits Nortel. CAUTION ACHTUNG Achtungshinweise bieten Informationen dazu, wie man mögliche Dienstunterbrechungen oder Schäden an Nortel-Produkten verhindert.
Safety Messages 13 WARNING WARNUNG Warnhinweise bieten Informationen dazu, wie man Personenschäden bei der Arbeit mit Nortel-Produkten verhindert. WARNING ADVERTENCIA Los avisos de Advertencia brindan información acerca de cómo prevenir las lesiones a personas al trabajar con productos Nortel. WARNING AVISO Os avisos oferecem informações sobre como evitar ferimentos ao trabalhar com os produtos da Nortel.
Regulatory Information and Safety Precautions DANGER PERIGO Avisos de Perigo—Alta Tensão oferecem informações sobre como evitar uma situação ou condição que possa causar graves ferimentos ou morte devido a alta tensão ou choques elétricos. DANGER PERICOLO Le indicazioni Pericolo—Alta tensione forniscono informazioni per evitare situazioni o condizioni che potrebbero causare gravi danni alle persone o il decesso a causa dell’alta tensione o di scosse elettriche.
. Software license This section contains the Nortel Networks software license. Nortel Networks Inc. software license agreement This Software License Agreement ("License Agreement") is between you, the end-user ("Customer") and Nortel Networks Corporation and its subsidiaries and affiliates ("Nortel Networks"). PLEASE READ THE FOLLOWING CAREFULLY. YOU MUST ACCEPT THESE LICENSE TERMS IN ORDER TO DOWNLOAD AND/OR USE THE SOFTWARE. USE OF THE SOFTWARE CONSTITUTES YOUR ACCEPTANCE OF THIS LICENSE AGREEMENT.
Software license of this Agreement. Customer shall not a) use, copy, modify, transfer or distribute the Software except as expressly authorized; b) reverse assemble, reverse compile, reverse engineer or otherwise translate the Software; c) create derivative works or modifications unless expressly authorized; or d) sublicense, rent or lease the Software. Licensors of intellectual property to Nortel Networks are beneficiaries of this provision.
Nortel Networks Inc. software license agreement 17 software documentation and, in the event Software is licensed for or on behalf of the United States Government, the respective rights to the software and software documentation are governed by Nortel Networks standard commercial license in accordance with U.S. Federal Regulations at 48 C.F.R. Sections 12.212 (for non-DoD entities) and 48 C.F.R. 227.7202 (for DoD entities). 2. Customer may terminate the license at any time.
Software license Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
. New in this release The following sections detail what’s new in Nortel Ethernet Routing Switch 8300 Installation — Chassis Installation and Maintenance, NN46200-309 for Release 4.1: • • “Features” (page 19) “Other changes” (page 19) Features See the following sections for information about feature changes: • • “8005DC power supply” (page 19) “Dual input DC-DC switching power supply” (page 19) 8005DC power supply Release 4.1 introduces the 8005DC power supply.
New in this release Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
. Introduction The Nortel Ethernet Routing Switch 8300 chassis provides the physical framework for the Nortel Ethernet Routing Switch 8300 modules. This document provides the instructions for installing the Nortel Ethernet Routing Switch 8300 chassis (8306 and 8310 chassis) in an equipment rack. This document also describes some of the routine tasks that you use to operate the Nortel Ethernet Routing Switch 8300 and includes technical specifications for the chassis and modules.
Introduction Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
. Chassis installation fundamentals This chapter describes fundamental information that you need for installing the Ethernet Routing Switch 8300 chassis (8306 and 8310 chassis) . Each Ethernet Routing Switch 8300 chassis consists of a sheet metal enclosure and a backplane. The number of bays for fan trays depends on the chassis type. For information about the minimum software versions required to support the hardware, see Nortel Ethernet Routing Switch 8300 Administration, NN46200-604.
Chassis installation fundamentals modules. Slots are numbered from the top down. You can install 8300 Series I/O switch modules in slots 1 through 4 and slots 7 through 10. Slots 5 and 6 are reserved for the 8393SF/CPU or 8394SF/CPU modules. The Ethernet Routing Switch 8310 chassis has three bays for either AC or DC power supplies and two fan trays for cooling.
Ethernet Routing Switch 8306 chassis 25 Figure 1 Ethernet Routing Switch 8310 chassis and components Ethernet Routing Switch 8306 chassis The Ethernet Routing Switch 8306 chassis provides four slots for installing I/O modules and two slots for installing Ethernet Routing Switch 8393SF/CPU or 8394SF/CPU modules. See Figure 2 "8306 chassis and components" (page 26). You can use the top four slots to install 8300 I/O switch modules.
Chassis installation fundamentals • • Ethernet Routing Switch 8348TX-PWR module or Ethernet Routing Switch 8348GTX-PWR module CAUTION Risk of equipment damage Do not install Ethernet Routing Switch 8300 modules and Ethernet Routing Switch 8100 or 8600 modules within the same chassis. Ethernet Routing Switch 8300 Series software does not support mixed configurations. A mixed configuration can damage the modules and void your warranty.
Site requirements • • 27 8005DC 8005DI DC, The PoE feature requires the following components: • • • Ethernet Routing Switch 8306 or 8310 chassis with PoE backplane Ethernet Routing Switch 8301AC or 8302AC power supply Ethernet Routing Switch 8393SF/CPU or 8394SF/CPU module and a choice of either of the following: • • Ethernet Routing Switch 8348TX-PWR module Ethernet Routing Switch 8348GTX-PWR module Fan trays Table 1 "Number of fan trays installed for each chassis" (page 27) lists the number of f
Chassis installation fundamentals Use the following guidelines to plan front and rear access: • The maintenance aisle in front of the frame requires a clearance of 76.2 centimeters (cm) (30 inches). • The wiring aisle at the back of the frame requires a clearance of 61 cm (24 inches). AC input electrical requirements Refer to the power specifications for the power supply in “Technical specifications” (page 55).
Hardware requirements 29 Table 3 Chassis shipping accessories: Ethernet Routing Switch 8310 and 8306 chassis Check Accessory Use to Bracket kit containing the following: Prepare the chassis for installation in an equipment rack. • • two rack mounting brackets bracket- mounting machine screws, each being 0.164 inches wide, 32 threads to the inch and 0.250 inches long — The 8310 chassis ships with 24 of these screws. — The 8306 chassis ships with 14 of these screws.
Chassis installation fundamentals Figure 3 Items in the Ethernet Routing Switch 8310 chassis shipping container Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
Hardware requirements 31 Figure 4 Items in the Ethernet Routing Switch 8306 chassis shipping container Other equipment In addition to the items that are included in the Ethernet Routing Switch 8310 and 8306 chassis accessory package you must also supply other items. Before you install the hardware, ensure that you have all the cables, tools, and other equipment that you need.
Chassis installation fundamentals Cables Unless you specifically order them, the cables required for your network configuration are not included in the chassis accessory package. If you do not have the proper cables, contact your network administrator.
. Ethernet Routing Switch 8310 and 8306 chassis installation This section describes how to install the Ethernet Routing Switch 8310 and 8306 chassis. CAUTION ESD To prevent damage from electrostatic discharge, always wear an antistatic wrist strap connected to an electrostatic discharge (ESD) jack when performing maintenance on this product. Ensure that the wrist strap makes contact with your skin. Prerequisites • Inspect all items for shipping damage.
Ethernet Routing Switch 8310 and 8306 chassis installation Navigation • • • “Chassis installation time requirements” (page 35) “Reducing the chassis weight” (page 35) “Installing the chassis on a flat surface” (page 35) Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
Installing the chassis on a flat surface • “Mounting the Ethernet Routing Switch 8310 and 8306 chassis in an equipment rack” (page 36) • “Installing the cable guides” (page 40) 35 Chassis installation time requirements The following table lists procedures you must use to install the Nortel Ethernet Routing Switch 8300 chassis and the estimated time you need to complete each procedure. Not all procedures are required for every Ethernet Routing Switch 8300 system.
Ethernet Routing Switch 8310 and 8306 chassis installation Prerequisites • Provide adequate space around the unit for access to cable connectors. • Ensure that the surface can safely support the weight of the chassis, its components, and its attached cables. See “Chassis installation time requirements” (page 35). Procedure steps Step Action 1 Set the switch on the flat surface and check for proper ventilation. Allow at least 2 inches 5.1 cm) on each side for proper ventilation and 5 inches (12.
Mounting the Ethernet Routing Switch 8310 and 8306 chassis in an equipment rack 37 Prerequisites • To mount the chassis in an equipment rack, you need the following equipment: — standard 19 in. (48.
Ethernet Routing Switch 8310 and 8306 chassis installation 2 Insert and tighten the supplied flat-head screws to fasten each bracket to the chassis. 3 Measure the appropriate number of rack units of free vertical space inside the rack and mark the spot. The following table shows the number of rack units you can allocate for each chassis. Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
Mounting the Ethernet Routing Switch 8310 and 8306 chassis in an equipment rack 4 Chassis Rack units Inches 8310 13.2 23.06 8306 9.7 16.9 Holding the chassis in position, align the flanged end of each mounting rail with two holes on each side of the vertical rack support. It is easier to complete this step with two people. Make sure that the hole pairs on either side of the vertical support match horizontally. 5 Insert and tighten the rack-mounting screws with a Phillips screwdriver.
Ethernet Routing Switch 8310 and 8306 chassis installation --End-- Procedure job aid: Maximum number of chassis installed in 7-foot rack The following table shows the maximum number of chassis that you can install in a 7-foot rack. Chassis Maximum number of chassis installed in 7-foot rack 8310 3 8306 4 Installing the cable guides Install the cable guides to keep cable clusters fastened and out of the way, but still accessible for maintenance.
Installing the cable guides 41 Procedure steps Step Action 1 Loosen, but do not remove, the rack-mounting screws needed to install one cable guide. 2 Slide the guide onto the loosened screws. 3 Tighten the screws to secure the guide to the chassis. Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
Ethernet Routing Switch 8310 and 8306 chassis installation --End-- Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
. Switch operations This chapter describes some of the procedures that you perform to operate the Ethernet Routing Switch 8300 and provides troubleshooting information.
Switch operations ATTENTION When you first install a chassis that contains two or three power supplies, you must turn on two of the power supply units simultaneously. If you wait longer to turn on the second power supply, one of the power supplies could shut down. To correct this condition, turn off both power supplies, wait at least 30 seconds, and then turn on both power supplies again simultaneously. For more information about the power switch locations, see the following figure.
Resetting the switch 45 The number of supported Power over Ethernet (PoE) modules depends on the power supply rating (110 volts [V]AC nominal or 220 VAC nominal), the power supply model, and the number of power supplies. For more information, see Ethernet Routing Switch 8300 Planning — Power Considerations, (NN46200-511). Prerequisites • • Ensure that the power supply is seated properly. Verify that the AC power cords are connected to the power supplies and connected to AC power outlets.
Switch operations Procedure steps Action To warm-start the Ethernet Routing Switch 8300 Series (no diagnostic tests are run), press the Reset button for less than 5 seconds. To press the Reset button, insert a small pointed object (for example, an unbent paper clip) into the Reset button hole. The following figure shows the location of the Reset button on the Ethernet Routing Switch 8393SF/CPU module.
Removing removable flash memory cards 47 2 Insert the card into the card receptacle. 3 Gently push the card in until it fits snugly in place. --End-- Removing removable flash memory cards Remove a removable flash memory card from the Ethernet Routing Switch 8393SF/CPU or 8394SF/CPU module to stop using it as a storage medium. Procedure steps Step Action 1 Press the eject button to the side of the memory card receptacle on the Ethernet Routing Switch 8393SF/CPU or 8394SF/CPU module.
Switch operations Protecting memory card files Write-protect the memory card for backup purposes after you successfully load the configuration file and save your configuration because Nortel ships each memory card with the read-write protect switch in the unprotected position. Typically, you do not operate the switch with a write-protected memory card. Make a copy of your configuration on another memory card, write-protect that card, and store it in a safe place.
Protecting memory card files 4 Reinsert the memory card into the card receptacle. --End-- Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
Switch operations Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
. Part Numbers This chapter provides a list of Nortel Ethernet Routing Switch 8300 hardware and part numbers. The following table lists Ethernet Routing Switch 8300 hardware and part numbers. Table 4 Ethernet Routing Switch 8300 hardware part numbers Part number Item Additional details DS1402007-E5 8310 10 slot Power over Ethernet (PoE) chassis Includes chassis, dual backplane, two fan trays, RS232 cable the for the management console, rack mount kit, and cable guide kit.
Part Numbers Table 4 Ethernet Routing Switch 8300 hardware part numbers (cont’d.) Part number Item Additional details DS1404099-E5 Ethernet Routing Switch 8394SF CPU/Switch Fabric module with 2 - 10 Gigabit Ethernet XFP slots Includes PCMCIA flash memory card. One switch fabric module is required for each Ethernet Routing Switch 8300 chassis. DS1404077-E5 Ethernet Routing Switch 8348TX module.
Protecting memory card files 53 Table 4 Ethernet Routing Switch 8300 hardware part numbers (cont’d.) Part number Item Additional details DS1405A14-E5 8301AC 100-240 volts (V) AC Power Supply. At least one power supply is required for each 83xx chassis. Provides up to 800W of PoE. Does not include a power cord. DS1405x16-E5 8302AC 100-240 V AC Power Supply. At least one power supply is required for each 83xx chassis. Provides up to 400W of PoE. Does not include a power cord.
Part Numbers Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
. Technical specifications This chapter lists the physical, environmental, and electrical specifications for the Ethernet Routing Switch 8310 and 8306 chassis and the available power supplies.
Technical specifications Table 5 Ethernet Routing Switch 8310 chassis physical specifications (cont’d.) Physical specifications Depth: 19.9 in. (50.5 cm) Weight (empty): 85 pounds (lb) (39 kilograms [kg]) Weight (fully loaded): 225 lb (102 kg) Cooling system: Fan trays: 2 per chassis Fans: 8 per fan tray Thermal sensors: 1 per fan tray Environmental specifications The following table lists the environmental specifications of the Ethernet Routing Switch 8310 chassis.
Ethernet Routing Switch 8306 chassis specifications 57 Table 7 Ethernet Routing Switch 8310 international regulatory requirements (cont’d.) International regulatory requirements U.S.: FCC CFR47 Part 15, Subpart B, Class A Canada: ICES-003, Issue-2, Class A Europe: EN 55022-1998 Class A; EN 61000-3-2/A14, EN 61000-3-3 (CE Marking Australia/New Zealand: AS/NZS 3548:1995, Class A Japan: VCCI-V3/97.
Technical specifications Table 8 Ethernet Routing Switch 8306 physical specifications (cont’d.) Physical specifications Weight (fully loaded): 140 lb (63 kg) Cooling system: Fan tray: 1 per chassis Fans: 6 per fan tray Thermal sensors: 1 per fan tray Environmental specifications The following table lists the environmental specifications of the Ethernet Routing Switch 8306 chassis.
Ethernet Routing Switch 8301 AC power supply specifications Table 10 Ethernet Routing Switch 8306 international regulatory requirements (cont’d.) International regulatory requirements Europe: EN 55022-1998 Class A; EN 61000-3-2/A14, EN 61000-3-3 (CE Marking) Australia/New Zealand: AS/NZS 3548:1995, Class A Japan: VCCI-V3/97.
Technical specifications Table 11 Ethernet Routing Switch 8301 AC power specifications (cont’d.) DC Output Power Ratings Max. output power (combined): 1140 W (1050 W + 90 W fans) 1770 W (1680 W + 90 W fans) Non-PoE: 3.3 VDC @ 150 A 3.3 VDC @ 150 A 12 VDC @ 65 A 12 VDC @ 65 A PoE: 50 VDC @ 18 A 50 VDC @ 18 A Fans: 12 volts (V)DC @ 7.5 A 12VDC @ 7.
Ethernet Routing Switch 8005DC power supply specifications 61 Table 12 Ethernet Routing Switch 8302 AC power specifications (cont’d.) Heat dissipation (thermal/output): 1126 BTU/hr 1195 BTU/hr Hold-up time: 20 ms 20 ms DC Output Power Ratings Max. output power (combined): 850 W (760 W + 90 W fans) 1400 W (1310 W + 90 W fans) Non-PoE: 3.3 VDC @ 150 A 3.3 VDC @ 150 A 12 VDC @ 65 A 12 VDC @ 65 A PoE: 50 VDC @ 18 A 50 VDC @ 18 A Fans: 12 VDC @ 7.5 A 12VDC @ 7.
Technical specifications The following table lists the DC output power specifications. Parameter Specifications Output power (maximum) 1462 W (1372 W + 90 W fans) Modules 3.3 V @ 150 A 12 V @ 72 A Fans 12 VDC @ 7.5 A/ 24 A peak Mean time before failure (MTBF) 108 803 hr (Bellcore TR–332 standard) Ethernet Routing Switch 8005DI DC power supply specifications This section provides power ratings for the 8005DI DC power supply. The following table lists the DC input power specifications.
. Translations of safety messages Class A device caution statement CAUTION This device is a Class A product. Operation of this equipment in a residential area is likely to cause harmful interference, in which case users are required to take appropriate measures necessary to correct the interference at their own expense. CAUTION ATTENTION Le périphérique est un produit de Classe A.
Translations of safety messages CAUTION ATTENZIONE Questo dispositivo è un prodotto di Classe A. Il funzionamento di questo apparecchio in aree residenziali potrebbe causare interferenze dannose, nel cui caso agli utenti verrà richiesto di adottare tutte le misure necessarie per porre rimedio alle interferenze a proprie spese.
Electrostatic discharge caution statement 65 CAUTION ATTENZIONE ESD Per evitare danni derivanti da scariche elettrostatiche, indossare sempre un polsino antistatico collegato a una presa di scarico elettrostatico (ESD) durante la manutenzione del prodotto. Accertarsi che il polsino sia a contatto con la pelle. Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
Translations of safety messages Nortel Ethernet Routing Switch 8300 Installation — Chassis NN46200-309 01.01 Standard 16 June 2008 Copyright © 2008 Nortel Networks .
Nortel Ethernet Routing Switch 8300 Installation — Chassis Copyright © 2008 Nortel Networks All Rights Reserved. Printed in Canada and the United States of America Release: 4.1 Publication: NN46200-309 Document status: Standard Document revision: 01.01 Document release date: 16 June 2008 To provide feedback or to report a problem in this document, go to www.nortel.com/documentfeedback. www.nortel.
