IP Softphone 2050 Settings
98
You can set the lamp to illuminate under the following conditions:
• Manual Override
• Headset Disconnect
• Active Call
• Message Waiting
Select the cadence (how the lamp illuminates) that you want to use for
each of the above conditions. Available cadences include:
•None
•On
•Flash
• Flicker
• Blink
Manual Override
With Manual Override enabled, you can turn on the external lamp by
pressing the Smart Functions button on your USB Headset Adapter.
To enable Manual Override, select the cadence you want from the list. To
disable Manual Override, select None.
Headset Disconnect
With Headset Disconnect enabled, the external lamp activates when the
headset registers as disconnected from the USB Headset Adapter.
To enable Headset Disconnect, select the cadence you want from the list.
To disable Headset Disconnect, select None.
Active Call
With Active Call enabled, the external lamp activates when the
IP Softphone 2050 registers an active call.
To enable Active Call, select the cadence you want from the list. To
disable Active Call, select None.
