16 Fundamentals
ATTENTION
You must install the MCG 3100 software on a dedicated server that runs no
other applications.
Hardware components
The MCG 3100 server runs only on the following supported commercial
off-the-shelf (COTS) hardware:
•
HP DL320G4 (NTDU97AAE5)
• IBM x306m (NTDU99AAE5)
Table 2 "Hardware requirements" (page 16) describes the supported
hardware requirements.
Table 2
Hardware requirements
Hardware Specification
Processor 3.0 GHz
Memory 2 GB DRAM
Hard Disk Drive 1-80 GB SATA Disk
Network Interface Card 2 1-GB Ethernet Cards
Power Supply 1 power supply
Software components
The MCG 3100 software installation includes the following software
components:
• Mobile Communication Gateway (MCG) 3100—enables the clients to
access advanced collaborative IP telephony services on the enterprise
network. Using the clients, users can search the corporate directory,
manage voice mail, dial by extension number, and hold group calls
with predefined groups of users.
•
MCG 3100 Administration Server—includes the Web Console, a
Web-based tool that administrators use to start, stop, and reload
server processes, update operating parameters, monitor users, track
messaging statistics, and manage the distribution of client software.
The Administration server also includes a database of server activity.
• MCG 3100 Group Call Server—hosts ad hoc conference calls with
predefined groups of users within the enterprise network. The Group
Call server includes a database of group call activities.
Nortel Mobile Communication 3100 Series Portfolio
Nortel Mobile Communication Gateway 3100 Installation and Upgrades
NN42030-300 02.03 Standard
9 May 2008
Copyright © 2007, 2008 Nortel Networks
.
