The port shortcut menu (Figure 12) provides a faster path for editing and graphing
a single port; however, you can access the same options using the menu bar or the
toolbar.
Figure 12 Port shortcut menu
Table 8 describes the commands on the port shortcut menu.
The MDA shortcut menu (Figure 13) contains a single command, Edit, that opens
a read-only dialog box with basic hardware information about the MDA.
Figure 13 MDA shortcut menu
Table 8 Port shortcut menu commands
Command Descriptions
Edit Opens a dialog box that allows you to set operating parameters
for the port.
Graph Opens a dialog box that displays statistics for the port and
allows you to display the statistics as a graph.
Enable Administratively brings a port up.
Disable Administratively shuts down a port. The color of the port
changes to red in the device view.
