User's Manual

40 Chapter 3 Device Manager basics
209321-A
Figure 10 Port color legend
Shortcut menus
Each object in the device view has a shortcut menu that opens when you
right-click a selected object. The switch shortcut menu (Figure 11) provides
access to basic hardware information about the switch and to the graphing dialog
boxes for the switch.
Figure 11 Switch unit shortcut menu
Table 7 describes the commands on the switch unit shortcut menu.
Table 7 Switch unit shortcut menu commands
Command Description
Edit Opens a read-only dialog box that provides
basic hardware information about the switch.
Graph Opens a dialog box that displays statistics for
theswitchandallowsyoutodisplaythe
statistics as a graph.
