Chapter 3 Device Manager basics 37
Getting Started with the Business Policy Switch 2000 Management Software
Selecting objects
The types of objects contained in the device view are:
A standalone switch (called a unit in the menus and dialog boxes)
A switch stack (called a chassis in the menus and dialog boxes)
A media dependent adapter (MDA) (called a unit in the menus and dialog
boxes)
A port
Figure 8 Objects in the device view
Selecting a single object
To select a single object:
Click the edge of the object.
The object is outlined in yellow, indicating that it is selected. Subsequent
activities in Device Manager refer to the selected object.
Switch unit or
Port object
MDA object
chassis object
