Chapter 3 Device Manager basics 35
Getting Started with the Business Policy Switch 2000 Management Software
Figure 7 Parts of the Device Manager window
Menu bar
Use the menu bar to set up and operate Device Manager (Table 4).
Table 4 Menu bar commands
Command Description
Device Opens the Open Device dialog box.
Edit Opens edit dialog boxes for selected objects in the device view (refer to
“Selecting objects” on page 37). This command also opens dialog boxes
for managing files and running diagnostic tests.
Graph Opens statistics dialog boxes for the selected object.
VLAN Opens dialog boxes for managing VLANs, spanning tree groups (STGs),
and Multi-Link Trunks.
Rmon Opens RMON configuration and monitoring dialog boxes.
Actions Provides quick opening of a Telnet session without going through other
dialog boxes.
Help Opens online Help topics for Device Manager and provides a legend for
the port colors in the device view.
Menu bar
Toolbar
Device view
Status bar
