34 Chapter 3 Device Manager basics
209321-A
3 In the Read Community and Write Community text boxes, type the proper
community strings (Table2onpage32).
4 Click Open.
Device Manager automatically determines what version of software the
selected device is running and displays the appropriate Device Manager
dialog boxes. The Device Manager window opens, showing a picture of the
device (Figure 6) that represents the physical features of the device.
Figure 6 Device view
Device Manager window
The Device Manager window (Figure 7) has the following parts:
•Menubar
• Toolbar
• Device view
• Status bar
Note: To gain Read-Write-All access to a device in Device Manager,
you must enter the Read-Write-All community string for both the Read
Community and Write Community strings.
