Switch User Manual

Electrical specifications

•

Input voltage: 100 to 240 VAC at 47 to 63 Hz

• Input power consumption: 400 W maximum

• Input volt amperes rating: 440 VA maximum

• Input current: 4.5 A @ 100 VAC, 2.25 A @ 240 VAC

• Maximum thermal rating: 575 BTU/hr

Physical specifications

Weight: 5.8 kg (12.76 lb)

Height: 7.04 cm (2.77 in.)

Width: 43.82 cm (17.25 in.)

Depth: 38.35 cm (15.1 in.)

Environmental specifications

•

Operating temperature: 0° to 40° C (32° to 104°F)

• Storage temperature: –25° to 70° C (-13° to 158°F)

• Operating humidity: 85% maximum relative humidity, non-condensing

• Storage humidity: 95% maximum relative humidity, non-condensing

• Operating altitude: Up to 3024 m (10,000 ft.)

• Storage altitude: Up to 3024 m (10,000 ft.)

Safety agency approvals

•

UL listed (UL 60950)

• CUL (CAN/CSA-22.2 No. 60950)

• CB certificate and report with all national deviations

(IEC 60950/EN60950)

Electromagnetic emissions summary

Meets the following standards:

• United States: FCC CFR47 PART 15, SUBPART B, Class A

• Canada: ICES-003, ISSUE-3, Class A

• Australia/New Zealand: AS/NZ 3548: 1995/A1:1997/A2; 1997, Class A

• Japan: VCCI-V-3/02.04/ Class A

• Taiwan: CNS 13438, Class A

• Europe: EN 55022-1998/A1:2000 Class A

• EMC Directive: 89/336/EEC: Directly published in the EMC Directive of 89/336/EEC with

• Modification 92/31/EED, 93/13/EC

• EN 61000-3-2: 2000

• EN 61000-3-3: 1995/A1:2001

• Global: CISPR 22-1997/A1:2000, Class A

Electromagnetic immunity

Global: CISPR 24:1997/A1:2001

Europe: EN55024:1998/A1:2001

Technical specifications

Table 1: BayStack 460-24T-PWR Power over Ethernet Switch technical specifications—continued
