Chapter 3
Configuration via Local Pages
E-DOC-CTC-20051017-0169 v0.1
89
Secondary DNS The IP address of the secondary DNS server, provided to the VPN clients via IKE
Mode Config. This is the secondary DNS server in the local network that is open to
VPN clients.
Primary WINS The IP address of the primary WINS server, provided to the VPN clients via IKE
Mode Config. This is the primary WINS server in the local network that is open to
VPN clients. A WINS server maps NETBIOS names to IP addresses.
Secondary WINS The IP address of the secondary WINS server, provided to the VPN clients via IKE
Mode Config. This is the secondary WINS server in the local network that is open to
VPN clients.
XAuth Pool The SpeedTouch™ allows the optional use of the Extended Authorization protocol
with an internal list of authorized users. When you want to use XAuth, a list of
authorized users is to be composed. This is explained in section “3.5.7 VPN-Server-
XAuth Page” on page 90.
Once you have defined a named list or authorized users, select it from the XAuth
Pool list to activate the use of Xauth in the VPN server.
