4.7.1 Connection Parameters
Parameters table The table below shows the connection parameters.
Connection name
[name]
This symbolic name only has local significance inside the SpeedTouch™ router.
This parameter is not used in the Phase 2 negotiations with the remote Security
Gateway.
Peer [peer] Holds the symbolic name of the peer to which the connection applies.
Connection parameters
Parameter Keyword Description
Connection name name Mandatory. Symbolic name for the
connection, used internally in the
SpeedTouch™.
Peer peer Mandatory. Symbolic name of the peer
entity to which the IPSec connection is
set up.
Local network localnetwork Mandatory. The private local IP network
that has access to the IPSec connection.
Remote network remotenetwork Mandatory. The private remote IP
network that has access to the IPSec
connection.
Always-on alwayson Mandatory. The permanent character of
the connection can be enabled or
disabled.
Descriptors descr Mandatory.Symbolic name of the
Connection Security Descriptor.
Options options Optional. Refers an option list,
containing a number of options that
influence the VPN behaviour.
State state Enables or disables the connection
For a basic IPSec configuration only a subset of the peer parameters need to
be set to a specified value. Some parameters may remain unset.
